Installing Hollo with Docker: A Complete Guide

This guide covers setting up Hollo, an ActivityPub server, using Docker in a homelab environment with S3 Storage and NGINX Proxy Manager.

Hollo leans toward single user instances, but can be configured for more than one person. This guide focuses on a single user instance with external media storage and a PostGres database stored outside the docker container.

Note that there is a much easier route to try out Hollo! You can get up and running with just a single click using Railway. But of course I wanted to do it the hard way. 😄

Environment Overview

Here is my configuration. External storage isn’t necessary, but it saves space and keeps things tidy. By default, Hollo creates a local minio server for media storage. My composer file removed that and uses external storage instead.

• Host: Homelab server
• Container Management: Portainer
• Reverse Proxy: NGINX Proxy Manager
• Postgres Database: Stored on separate volume for easy backups
• DNS: Netlify, Cloudflare, Porkbun - up to you!
• CDN/Storage: External - you can use any S3-compatible storage, Hollo configures a local minio instance by default
• Domain Setup:
  • Main site: your-instance.example.com
  • Media: media.your-instance.example.com

Prerequisites

• Docker and Portainer installed
• NGINX Proxy Manager configured
• S3 bucket set up with your public and private keys and endpoint url
• Domain or sub-domain configured with your DNS provider

Domains are used for federation, and you should be warned that once you setup federation on that domain or sub-domain, it can’t be changed, and you can’t use it for another instance. Ever. So choose wisely! If you decided you want to change from Hollo to IceShrimp, you would need to use a different domain, otherwise you’re going to be getting a ton of traffic for the wrong platform.

Storage and Backup Strategy

Database Storage Location

The PostgreSQL data is stored in a custom location (e.g., /path/to/docker-volumes/hollo/data) instead of using Docker’s built-in volume management. I chose this option because it supports integration with an existing Borg backup solution I have in place following this excellent guide from GoToSocial: Backing Up Your GoToSocial Instance.

You could completely skip this and use Docker volumes, but I like the flexibility of managing the data backups.

1. Your chosen backup directory can be included in regular backup routines
2. Database files are automatically included in system backups
3. BorgBase has scripts ready to go for backing up PostgreSQL data
4. Data is easily accessible for backup verification or manual management
5. No need for separate database backup scripts

Docker Compose Configuration

I wandered off the beaten path a bit with my configuration. I wanted to use a custom location for the PostgreSQL data directory and external storage for media. In addition, I moved my secrets and other custom values into environment variables.

I also added a healthcheck, which is the first time I’ve done this on my own in a Docker Compose file. I was running against an issue where the Hollo container would start before the Postgres container was ready. This healthcheck and related “depends_on” section fixed that issue.

This composer file is based off official Hollo composer file, but it has been modified to suit my needs. Please refer to the official documentation before implementing this in your environment as it may have been updated since this post.

services:
  hollo:
    image: ghcr.io/fedify-dev/hollo:canary
    ports:
      - "3131:3000"
    environment:
      DATABASE_URL: postgres://${POSTGRES_USER}:${POSTGRES_PASSWORD}@postgres:5432/${POSTGRES_DB}
      SECRET_KEY: ${SECRET_KEY}
      LOG_LEVEL: ${LOG_LEVEL}
      BEHIND_PROXY: ${BEHIND_PROXY}
      DRIVE_DISK: s3
      ASSET_URL_BASE: "https://media.your-instance.example.com/"
      S3_REGION: us-east-1
      S3_BUCKET: your-bucket-name
      S3_ENDPOINT_URL: your-r2-endpoint.r2.cloudflarestorage.com
      S3_FORCE_PATH_STYLE: "true"
      AWS_ACCESS_KEY_ID: ${AWS_ACCESS_KEY_ID}
      AWS_SECRET_ACCESS_KEY: ${AWS_SECRET_ACCESS_KEY}
    depends_on:
      postgres:
        condition: service_healthy
    restart: unless-stopped

  postgres:
    image: postgres:17
    environment:
      POSTGRES_USER: ${POSTGRES_USER}
      POSTGRES_PASSWORD: ${POSTGRES_PASSWORD}
      POSTGRES_DB: ${POSTGRES_DB}
      PGDATA: /var/lib/postgresql/data/pgdata
    volumes:
      - /path/to/docker-volumes/hollo/data:/var/lib/postgresql/data
    healthcheck:
      test: ["CMD-SHELL", "pg_isready -U ${POSTGRES_USER} -d ${POSTGRES_DB}"]
      interval: 10s
      timeout: 5s
      retries: 10
      start_period: 30s
    restart: unless-stopped

Installation Steps

If you are not storing your PostgreSQL data in a custom location, you can skip the first step. I found permissions to be a bit tricky with LXD and Docker, so I’ve included a solution that worked for me.

1. Prepare PostgreSQL Data Directory

   cd /path/to/docker-volumes/hollo
   sudo mkdir data
   sudo chown lxd:docker data
   sudo chmod 770 data


2. Configure Environment Variables in Portainer

I moved all the secrets and custom values into environment variables in Portainer. This is a more secure way to manage secrets and allows for easy changes in the future.

SECRET_KEY is used to sign federation requests. It should be kept secure and not changed once federation is working. Don’t lose it!

You can generate the SECRET_KEY and POSTGRES_PASSWORD using openssl:

openssl rand -base64 32

POSTGRES_USER=hollo_user
POSTGRES_PASSWORD=your_secure_password
POSTGRES_DB=hollo
AWS_ACCESS_KEY_ID=your_r2_access_key
AWS_SECRET_ACCESS_KEY=your_r2_secret_key
SECRET_KEY=your_secure_random_key
LOG_LEVEL=info
BEHIND_PROXY=true

1. Configure DNS and NGINX Proxy Manager

The only tricky thing here is I had to use a Porkbun DNS challenge using their API for the SSL certificate, which isn’t well documented. I had to get an API Key and Secret from Porkbun and add them into the “Credentials File Content” field of the Let’s Encrypt DNS challenge prompt within NGINX Proxy Manager.

• DNS Provider: Create new A record for your-instance.example.com pointing to your server’s IP address
• NGINX: Create new proxy host
  • Domain: your-instance.example.com
  • Scheme: http
  • Forward to: http://your-docker-host:3131
  • SSL: Let’s Encrypt with a DNS challenge

Common Issues and Solutions

1. Port Configuration

Issue: Application not accessible Solution: Hollo must run on internal port 3000, but can be mapped to any external port. However, I had it set to 3131:3131 in my docker compose file initially.

ports:
  - "3131:3000" # External:Internal

2. It’s always DNS

Issue: Browser showing redirect loops or SSL errors Solution:

• Ensure your DNS / SSL configuration is correct (that is…a broad statement lol)
• Keep NGINX PM scheme as http for internal communication
• Set BEHIND_PROXY=true in Hollo configuration

My personal DNS issue was ensuring the NGINX Proxy Manager certificate and “Require SSL” setting were correct. Porkbun DNS challenge was a bit tricky, but once I got the API key and secret in NGINX PM, it worked like a charm.

Additional Notes

• Keep your SECRET_KEY backed up and don’t change it once federation is working
• Monitor PostgreSQL logs for any database issues
• Regular backups of the PostgreSQL data directory are recommended

Finishing Configuration

Access https://your-instance.example.com/setup to complete the initial configuration of your Hollo instance.

Follow Hollo’s official documentation to complete the configuration.

When I filled out the initial account creation form, it took a bit longer than I expected for a response to come back, but it finally did. So be patient if it takes a bit longer than you expect.

You probably want to upload a profile picture and a header image. I might be wrong about this, but it appears you can only do that from a client app. I used Fedicat, but there are tons to choose from that work with Hollo.

Now you’re ready to start hollo-ing! 🎉

Follow me on my Hollo instance: @[email protected]

Final Thoughts

When I first pulled up the Hollo setup page, it felt very familiar. It’s clean and simple, with large UI controls. I then realized it’s built with PicoCss, which is the same CSS framework I used for my little mastodon API playtoy, Devtodon. I love the simplicity and ease of use of PicoCss and glad to know others do, too!

Need to figure out why Hollo isn’t working with Devtodon. 🤔

Hollo is a great project and I’m excited to see where it goes. I’m happy to have it running in my homelab and look forward to seeing how it evolves. I hope this guide helps you get started with Hollo in your own environment.

Resources

• Hollo Official Documentation
• Hollo GitHub Repository
• PicoCss
• Backing Up Your GoToSocial Instance
• Docker Compose Healthcheck
